Vitocal 160-A
B
Silencer
C
Overflow apertures, e.g. gaps between door frames and door
leaves (gap height min. 0.8 to 1.2 cm)
D
Ventilation element
E
Extract valves
F
Silencer (optional) to reduce transmission of noise through reflec-
tions ("telephony effect")
G
Expelled air outlet
Flow velocity
0
1
2
3
4
5
6
7
Air flow rate in m³/h
Flow velocity in m/s
20 40
60
90 150 200
250 300 350 400
0
BA
A
Spiral-seam tube DN 125 (smooth inside)
B
Spiral-seam tube DN 160 (smooth inside)
Sizing
(cont.)
VITOCAL 160-A
