Initial start−up, inspection and maintenance
Stepsinitial start−up, inspection and maintenance
For further instructions on individual steps, see pages indicated.
Commissioning steps
Inspection steps
Maintenance steps Page
C M
1. Adjusting pressure regulator and pressure limiter 6. . . . .
C M
2. System start−up 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M
3. System shutdown 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I M
4. Closing the Vitoair draught stabiliser (if installed) 9. . . . .
M
5. Opening the boiler door and the clean−out cover 9. . . . . . .
M
6. Removing and cleaning the turbulators 10. . . . . . . . . . . . . . . . . . . . . . . . . .
M
7. Cleaning heating surface, flue outlet and flue pipe 11. . . .
I M
8. Checking all seals/gaskets and packing cords
on flue gas side
M
9. Checking thermal insulation of boiler door
M
10. Inserting the turbulators 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M
11. Securing the boiler door and clean−out cover 13. . . . . . . . . . . . . . .
M
12. Checking the water chamber for deposits 14. . . . . . . . . . . . . . . . . . . . . .
M
13. Cleaning the multiple level electrode 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M
14. Cleaning the water level indicator 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M
15. Checking all connections at the water and
steam sides, the sensor well and the
inspection ports for leaks after filling the boiler 16
. . . . . . . . . .
I M
16. Cleaning the sight glass in the boiler door 16. . . . . . . . . . . . . . . . . . . .
I M
17. Checking the Vitoair draught stabiliser (if installed) 17.
M
18. Adjusting the burner 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I M
19. Checking the safety valve 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I M
20. Checking the safety and control equipment
