8
Note
On gas burners, disconnect the gas supply pipe.
4x
Fig. 1
Cleaning the turbulators, heating surface, flue outlet and flue pipe
CBA
Fig. 2
1.
Remove turbulators
A
without applying force.
2.
Clean flues
B
and combustion chamber
C
with
the brush.
Remove combustion residues with a vacuum
cleaner.
D
Fig. 3
3. Remove combustion residues from the flue and the
flue outlet through the cleaning aperture in flue out-
let
D
using a vacuum cleaner.
Commissioning, inspection, maintenance
Opening the boiler door and cleaning cover
5692 701 GB
