Viessmann VITOPLEX 300 - Cleaning the internal pipes, heating surface, flue outlet and flue pipe

10
Cleaning the internal pipes, heating surface, flue outlet and flue
pipe
1.
Remove internal pipes B with a
quick tug towards the front; for this,
use internal pipe extractor
A
, which
is part of the cleaning equipment.
2.
Clean flues C and combustion
chamber
D
with the brush.
Remove combustion residues with a
vacuum cleaner.
3. Remove combustion residues from
the flue and the flue outlet through the
clean-out aperture in flue outlet
E
using a vacuum cleaner.
Commissioning, inspection, maintenance
Further details regarding the individual steps
(cont.)
5692 798
