17
Information regarding the ordering of
spare parts
Quote the part and serial no. (see type
plate) and the item no. of the required
part (as per this parts list).
Obtain standard parts from your local
supplier.
Parts
001 Boiler door
002 Stud
003 Sight glass pack, comprising pos.
004 to 007
004 Sight glass frame pack
005 Gasket
006 Hose ferrule
007 Plastic hose
008 Hose pack Ø 18 mm
009 Upper insulation block
010 Lower insulation block
011 Thermal insulation mat
012 Packing GF 25 × 15
013 Internal pipe
014 Gasket, flow/return
015 Gasket, safety valve
016 Clean-out cover
017 Packing
018 Sensor well, boiler water
temperature sensor
019 Sensor well, Therm-Control
temperature sensor
200 Cover panel, front
201 Cover panel, back
202 Top front panel (only for 1600 to
2000 kW)
203 Top front and back panel
204 Bottom front panel
205 Back panel, bottom
206 Side panel
207 Side panel, control unit
208 Centre rail
209 Front r.h. rail
210 Front l.h. rail
211 Back r.h. rail
212 Back l.h. rail
213 Thermal insulation jacket
214 Thermal insulation jacket, centre
(only for 1000 to 2000 kW)
215 Thermal insulation mat, back
216 Insulation mat, l.h. back
217 Insulation mat, r.h. back
218 Mounting panel, back
219 Mounting panel
220 Channel retainer
221 Top part, cable duct
222 Bottom part, cable duct
223 Edge protector
224 Cover, sensor coupling
225 Front insulation mat
226 Insulation mat, l.h. front
227 Insulation mat, r.h. front
Wearing part
020 Cleaning brush
Accessories
021 Cleaning equipment complete (incl.
extraction hook and pos. 20)
022 Burner plate pack
023
Burner plate gasket
*1
Parts not shown
300 Thermal insulation pack
301 Touch-up spray, Vitosilver
302 Touch-up paint stick, Vitosilver
303 Installation instructions
304 Service instructions
305 Decorative adhesive tape
*1
for sizes 620 and 780 kW with seal ring,
for sizes 1000 and 2000 kW with glass fibre-reinforced fabric ribbon
Parts lists
Parts lists
5692 798
