Initial start-up
Further step-by-step instructions
(continued)
Single boiler system with Vitotronic 050 and Vitocom 300
Participant no. 1
Coding 77: 1
Participant no. 10
Coding 77: 10
Participant no. 11
Set Coding 77: 11
Participant no. 99
Control unit is
fault manager
*1
Coding 79: 1
––– Control unit is not fault manager
*1
Coding 79: 0
Control unit is
fault manager
(fixed)
Send time via
LON
Coding 7b: 1
Time received via LON
Set Coding 81: 3
Time received via LON
Set Coding 81: 3
Time received
via LON
(fixed)
Send outdoor
temperature via
LON
Coding 97: 2
Outdoor temperature is received via LON
Set Coding 97: 1
Outdoor temperature is received via LON
Set Coding 97: 1
–––
System number
Coding 98: 1
System number
Coding 98: 1
System number
Coding 98: 1
–––
Fault monitoring
LON participant
Coding 9C: 20
Fault monitoring
LON participant
Coding 9C: 20
Fault monitoring
LON participant
Coding 9C: 20
–––
*1
In each heating system, only one Vitotronic may be encoded as fault manager.
