Components
Remote control (cont.)
D Never adjust the PCB DIP switch (back of the remote
control) except when connecting a separate sensor
Specification
Power supply via KM BUS.
Safety class: III
Protection: IP 30
Permiss. ambient
temperature
during operation:
0 to +40ºC
32 to 104ºF
in storage and transport:
–20 to +65ºC
–4 to +149ºC
Set room temperature
setting range:
10 to 30ºC
50 to 96ºF
adjustable between
3 to 23ºC
37 to 73ºF
or
17 to 37ºC
63 to 99ºF
via coding address E1
Setting of the reduced set room temperature at the control
unit.
When connecting a separate room temperature sensor, set
DIP switch S6.3 to ON.
5285 967 v1.2
ON
S6
1 2 3 4
D
