Pre-plumbing jig (optional accessory)
To help installation of the Vitodens 100-W, all
connections are checked for leaks during the
assembly process and only need to be tested
again once the boiler is hung.
To complete the overall look of the installation
a boiler fittings cover is included.
1
Pre-plumbing jig with 2 cross bars
2
Valve/fittings cover
Rear pipework mounting frame
(optional accessory)
The mounting frame has the same benefits as
the pre-plumbing jig but with the ability
to allow 50 mm behind the frame for wiring
upwards behind the unit.
To complete the overall look of the installation
a boiler fittings cover can also be included.
1
Rear pipework mounting frame with 2
cross bars
2
Valve/fittings cover
Ease of installation : Optional accessories for commissioning
Easy commissioning and maintenance
1. Installation with pre-plumbing jig
2. Mounting the boiler
3. Electrical connection
4. Commissioning
With a few simple steps the Vitodens 100-W
can be installed and operating.
The Vitodens 100-W gas fired condensing
boilers are consistently designed for simple
installation and time saving servicing.
1. Installation with pre-plumbing jig 2. Mounting the boiler
3. Electrical connection 4. Commissioning
