8. Technical Specifications
8.1. CDE4600-L
Display:
Item Specications
Screen Size (Active Area) 46” LCD (116.8 cm)
Aspect Ratio 16:9
Number of Pixels 1920 (H) × 1080 (V)
Pixel Pitch 0.53025 (H) × 0.53025 (V) [mm]
Displayable Colors 16.7 Million colors
Brightness 350 cd/m²
Contrast Ratio (Typical) 5000:1
Viewing Angle 178 degrees
In/Out Terminals:
Item Specications
Speaker Output Internal Speakers 7W(L)+7W(R)[RMS]/16Ω,1Way1SpeakerSystem
82 dB/W/M/160 Hz ~ 13 KHz
Audio Output RCA Jack × 2 0.5V [rms] (Normal) / 2 Channel (L+R)
Audio Input 3.5 mm Stereo × 1
RCA Jack × 2
0.5V [rms] (Normal) / 2 Channel (L+R)
RS232C Input/
Output
2.5 mm × 2 TXD + RXD (1:1)
LAN RJ-45 Jack × 1
(8 pin)
10/100 LAN Port
HDMI Input HDMI Jack × 1
(Type A) (19 pin)
Digital RGB: TMDS (Video + Audio)
MAX:
Video: 720p, 1080p, 1920 × 1080/60 Hz (WUXGA)
Audio: 48 KHz / 2 Channel (L+R)
Supports LPCM only
DVI-D Input DVI-D jack Digital RGB: TMDS (Video)
VGA Input D-Sub Jack × 1
(15 pin)
AnalogRGB:0.7V[p-p](75Ω),H/CS/V:TTL(2.2kΩ),SOG:1V[p-p]
(75Ω)
MAX: 720p, 1080p, 1920 × 1080/60 Hz (WUXGA)
Component Input RCA Jack × 3 Y:1V[p-p](75Ω),Pb:0.7V[p-p](75Ω),Pr:0.7V[p-p](75Ω)
MAX: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p
SPDIF Output SPDIF Port Serial digital audio output when input is HDMI
IR Input/Output 3.5 mm × 2 IR pass through or IR daisy chain
USB Input USB × 1 (Type B) USB 2.0, External PC connection
General:
Item Specications
Power Input 100-240V
50-60Hz, 2.5A
Power Consumption (Max.) 104 W
Power Consumption (Typical) 88 W
Power Consumption (EPA6.0) 66 W
Power Consumption (Standby & Off) < 0.5W (OSD: APM mode off)
Dimensions [W × H × D] 1068 × 622.5 × 38.8 mm
Weight 13.7 Kg
Gross Weight 17.2 Kg
