7
y
You can set the Power indicator to on or off by selecting OPTION in the main menu.
Parts and buttons
Screen Marks Description
INPUT Changes the input source.
MENU Accesses the main menus, or saves your input and exits the menus.
Adjust the up and down.
Adjusts the volume level.
AUTO/SET Displays the current signal and mode.
Press this button to adjust the screen automatically (available only in RGB mode)
/I
Turns the power on or off.
IR Receiver This is where the unit receives signals from the remote control.
Power Indicator This Indicator lights up blue when the display operates normally(on mode). If the display
In sleep mode (In Power Saving mode), this indicator color changes to amber.
Connection panel
Screen Buttons
Screen Marks
IR Receiver /
Power Indicator
y
Lighting On: Turned on
y
Lighting Off: Turned off
NOTE
MEZ63829306(REV00)
