DVI-D connection
Transmits the digital video signal from your PC to
the Monitor. Connect the PC and the Monitor
set with the DVI cable as shown the following
illustrations.
Select DVI-D input source on the monitor.
RGB OUT (PC) AUDIO OUT
RGB connection
Transmits the analog video signal from your PC to
the Monitor. Connect the PC and the Monitor
set with the 15 pin signal cable as shown the
following illustrations.
Select RGB input source on the monitor.
y
Use the standard Macintosh
adapter since an incompatible
adapter is available in the
market. (Different signaling
system)
y
Apple computers may require an adapter to
connect to this monitor. Call or visit their web
site for more information.
NOTE
AUDIO OUT
DVI OUT
Macintosh Adapter
(not included)
(not included)
(not included)
(not included)
