USB and Networking Connecons

Just like any PC, it is easy to connect various USB devices and other peripherals to

your ViewBoard.

USB Peripherals

Plug the USB device cable into the USB port.

USB Cable

USB Device

Networking and Modem cables

Plug the network cable into the LAN port.

Network Cable

Internet

LAN
