ViewSonic LS700-4K - RS232 Command Table

65
62
5962
Address Code
Code 1 83F4
Code 2 93F4
Code 3 A3F4
Code 4 B3F4
Code 5 C3F4
Code 6 D3F4
Code 7 E3F4
Code 8 F3F4
RS232 command table
<Pin assignment for this two end>
Pin Description Pin Description
1 NC 2 RX
3 TX 4 NC
5 GND 6 NC
7 RTSZ 8 CTSZ
9 NC
<Interface>
RS-232 protocol
Baud Rate 115200bps (default)
Data Length 8 bit
Parity check None
Stop bit 1 bit
flow control None
<RS232 Command List>
The below table list all RS232 commands frequently used:
No. Function Type Action Command Response The response of Query Read command
1
Power
Write
ON
ON/
0x06 0x14 0x00 0x04 0x00 0x34 0x11
0x00 0x00 0x5D
0x03 0x14 0x00 0x00 0x00 0x14
0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x01
0x18
2 Power Write
Write
OFF
OFF
0x06 0x14 0x00 0x04 0x00 0x34 0x11
0x06 0x14 0x00 0x04 0x00 0x34 0x11
0x01 0x00 0x5E
0x03 0x14 0x00 0x00 0x00 0x14
0x03 0x14 0x00 0x00 0x00 0x14
0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x00
0x17
3 Power
Power Read Status
0x34 0x00 0x91
0x07 0x14 0x00 0x05 0x00 0x34 0x00
0x00 0x11 0x00 0x5E
0x05 0x14 0x00 0x03 0x00 0x00
0x00 0x01 0x18
5
4
Projector
Status
Read Status
(Note 7)
0x07 0x14 0x00 0x05 0x00 0x34 0x00
0x00 0x11 0x26 0x84
Warm up :0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x01 0x18
Cool down :0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x03 0x1A
Power On :0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x02 0x19
Power Down :0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x00 0x17
6 Reset All
Settings
Write Reset All
Settings
0x06 0x14 0x00 0x04 0x00 0x34 0x11
0x02 0x00 0x5F
0x03 0x14 0x00 0x00 0x00 0x14
