16
ENGLISH
Contact ViewSonic service team at: http://www.ViewSonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775
ViewSonic N4285p/N4785p
Getting Started
Item Description
12 HDMI 1 signal Audio input
(left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
13
YPbPr 2 signal Audio
input (left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
14
YPbPr 1 signal Audio
input (left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
15
AV/ S-Video signal Audio
input (left/right)
Connect the audio cable for AV or S-Video to this connector.
16
Audio output
Connect this port to your A/V device with audio in (RCA)
connectors or to audio amplier.
17
Headphone Jack
Connect to your headphones. By connecting the headphones,
you can listen to the sound from the TV on headphones.
＊
If you connect the headphones, the TV speakers will be
muted.
18
PC/ HDMI 2 Audio input
Connect this port to PC line out jack.
19
SPDIF Optical output
Connect this port to the SPDIF input of A/V device.
Note: There is a Service jack next to the HDMI Input Terminal [3].
It is for service technician’s use.
20
HDMI 3 signal Audio input
(left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
21
AV 2/ HDMI 3 signal Audio
input (left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
22
Composite Video input
(AV 2)
Connect this jack to the composite video output connectors on
your A/V equipment.
AV connection
Connect the composite video and audio input jacks to the corresponding output jacks of your
A/V device.
N4285p --- VIDEO: Composite Video input [9]
--- AUDIO: AV/ S-Video signal Audio input [15]
N4785p --- VIDEO: Composite Video input [9]
--- AUDIO: AV/ S-Video signal Audio input [15]
or
--- VIDEO: Composite Video input (AV 2) [22]
--- AUDIO: AV 2/ HDMI 3 signal Audio input [21]

ViewSonic N4285p Specifications

General

Response time	6.5 ms
Display diagonal	42 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewing angle, horizontal	176 °
S-Video inputs quantity	1
Component video (YPbPr/YCbCr) out	2
Headphone connectivity	3.5 mm
Product color	Black

Weight and Dimensions

Depth (with stand)	294 mm
Width (with stand)	1025 mm
Height (with stand)	773 mm
Weight (with stand)	29800 g
Depth (without stand)	139 mm
Height (without stand)	704 mm
Weight (without stand)	26100 g
