12
7.
MONITOR INSTALLATION
Monitor Installation
How to Install the Connections to your PC
7-1. Your monitor has two connection cables:
.A signal cable which connects to your computer's VGA connector. Which is colored blue.
7-2. To ensure your safety when connecting the cable, always follow these six steps:
(Ⅰ). Turn off the power to your computer and peripheral equipment.
(Ⅱ). Position the monitor and computer so that you can easily access the rear panel of each unit.
(Ⅲ). Connect the blue-colored video signal cable D-sub connector to the signal connector on the
graphics board (VGA connector) on your computer. (See your system user's guide for the
exact location of your VGA connector.)
(Ⅳ).Tighten the screws on the signal cable connector to prevent it from coming loose, and to
prevent radio and TV interference.
(Ⅴ).There are two kinds of Power Cord, one is to connect between your monitor and the wall
outlet, the other type is to connect between your monitor and PC.
- You might have either of the above two type of power cord. To connect the power cord
between monitor and PC, you have to plug one-end of the power cord to the monitor
power input socket, and plug the other end of the power cord to the PC power output
feed.
- To connect Power Cord between your monitor and wall outlet , you have to connect the
power cord to the monitor power input socket on back of the monitor .Plug the other ent
of the power cord into your surge protector or properly-grounded electrical outlet
ViewSonic Corporation
Confidential – Do Not Copy
P90f-1
