REPLACEMENT PARTS LIST
WARNING: Replacement parts that have special characteristics important to safety should
be replaced only with types identical to those in the original circuit or specified in the parts
list. Before replacing any of these components, read carefully the product safety
precautions. Do not degrade the safety of the display through improper servicing
ABBREVIATIONS:
RESISTOR
CAPACITOR
PART NAME & DESCRIPTION PART NAME & DESCRIPTION
TYPE ALLOWANCE TYPE ALLOWANCE
R Resistor F ±1% C Capacitor F ±1%
CF Carbon Film G ±2% CE Ceramic G ±2%
CC Carbon Composition J ±5% EL Electrolytic J ±5%
MOF Metal Oxide Film K
±10
PO Polyester K ±10%
FU Fusible M
±20
TA Tantalum M ±20%
MF Metal Film PP Polypropylene P ±100%–0%
VR Variable Resistor ME Metalized Z ±80%–20%
CR Cement Resistor BL Barrier Layer
SMD Thick Film Chip 1206 SMD Monolithic SMD 0805
ViewSonic Corporation
Confidential – Do Not Copy
ASSEMBLY PCB-MAIN (PWB-0334A)
CAPACITOR
CKT NO. Part no. Description
C100 5248439091 C. CE 2KV 39P J
C101 5234333191 C. CE 2KV 330PF K
C102 5223622201 CQ93T630V 2200PF J
C103 5213610091 C. EL 50V 1UF M
C104 5214701091 C. EL 450V 1UF M
C105 5275122491 C. ME 63V 0.22MF J
C106 5276110491 C. ME 100V 0.1UF J
C107 5205647991 C. EL 50V 4.7UF M
C108 5213601091 C. EL 50V 1UF M
C109 5236310491 C. BL 50V 0.1UF Z
C110 5231310291 C. CE 50V 1000PF K
C111 5275122491 C. ME 63V 0.22UF J
C112 5221122391 C. PO 50V 22000PF J
C114 5271133391 C. ME 100V 33000PF J
C115 5276110491 C. ME 100V 0.1UF J
C116 5213622091 C. EL 50V 22UF M
CKT NO. Part no. Description
C117 5227322291 C. ME 100V 2200PF J
C118 5214019612 100V 330UF
C120 5213639091 C. EL 50V 22UF M
C121 5236310491 C. BL 50V 0.1UF Z
C122 5213601091 C. EL 50V 1UF M
C123 5233310291 C. CE 1KV 1000PF K
C126 5232322291 C. CE 500V 2200PF K
C127 5232310291 C. CE 500V 1000LF K
C128 5223510201 C. PO 400V 1000PF K
C129 5213447091 C. EL 25V 47UF M
C130 5271110501 C. ME 100V 1UF J 35KHz
C131 5233310291 C. CE 1KV 1000PF K
C132 5223447301 C. PO250V 47000PF J5KHz
C133 5236310491 C. BL 50V 0.1UF Z
C134 5213610091 C. EL 50V 10UF M
C135 5214433012 C. EL 250V 33UF M
