38
CKT NO. Part no. Description
CA25 5242210191 C. CE 50V 100PF J
CA26 5242210191 C. CE 50V 100PF J
CA27 5231310291 C. CE 50V 1000PF K
SEMICONDUTOR
DIODE
CKT NO. Part no. Description
D101 6611032640 DIODE DIODE RECTIFIER BYV26DGP 800V 1A
D102 6615005836 DIODE ZENER HZ12A2-TD
D103 6611012849 DIODE RECTIFIER RGP10M
D104* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D105* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D108* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D109* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D110 (RA) 6615021430 DIODE ZENER BZX79C51
D110 (RB) 6615015640 DIODE ZENER IN5262B
D110 (RC) 6615021441 DIODE ZENER IN5262B-RL
D110A (CB) 6615005836 DIODE ZENER HZ12A2-TD
D110A (CB) 6615023331 DIODE ZENER HZ24-2-TD 23.6-24.7V
D111 6615012530 DIODE ZENER HZ4A2-TD 3.5-3.7V 5mA 0.5w
D112* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D113* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D114 (RA) 6613002244 DIODE SWITCHING RGP10D-G23
D114 (RB) 6611035644 DIODE SWITCHING RGP10D
D115 (RA) 6613002244 DIODE SWITCHING RGP10D-G23
D115 (RB) 6611035644 DIODE SWITCHING RGP10D
D116* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D118 (RA) 6615009752 DIODE ZENER RD6.8B2-T7
D118 (RB) 6615007234 DIODE ZENER HZ7B1-TD 6.7-7V
D119* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D120* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D125* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D126 (RA) 6611018200 DIODE RECTIFIER 30DF2
D126 (RB) 6611015245 DIODE RECTIFIER GUF30D
D127 6611035643 DIODE SWITCHING RGP10G
D128 6611019241 DIODE RECTIFIER BYD73G
D301 6615007834 DIODE ZENER HZ5C1-TD 4.9-5.1V
D310# 6611007240 DIODE RECTIFIER 1N4002RL(RA,RB,RC,RD)
D401* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA,RB,RC)
D402 (RA) 6615009336 DIODE ZENER BZX79C10
