ViewSonic P90F - Page 53

49
BASE & PIN
CKT NO Part no. Description
P02A
P301 5057415224 WIRE ASS’Y W/15P CONNUL/CSA1007#24 L=330MM
P302 5057404300 WIRE ASS’Y W/15P CONN UL/CSA1007#24 JST/JAE 400mm
P400 5056203901 PIN RT-01N-2.3A
P401 5056407801 BASE & PIN 2.36mm 4P(UL/CSA/TUV)
P409 5056203901 PIN RT-01N-2.3A
P410 5056203901 PIN RT-01N-2.3A
P420 5056415617 BASE & PIN
P421 5057405136 WIRE ASS’Y L=320MM
P422 5056415326 BASE & PIN 3P
P800 5057402199 WIRE ASS’Y W/2P CONN UL/CSA 1617 #22 LSINX2/SINX2350
P801 5056513117 AC SOCKEY 7014(A)
P803 5056415207 BASE & PIN 2.36mm 2P(UL/CSA/TUV)
PA03 5057402320 WIRE ASS’Y W/15P CONN
OTHERS
CKT NO Part no. Description
SA01 5054513025 TACT SWITCH SKHHLV1720-TT DC12V 50MA GRAY
SA02 5054513025 TACT SWITCH SKHHLV1720-TT DC12V 50MA GRAY
SA03 5054513025 TACT SWITCH SKHHLV1720-TT DC12V 50MA GRAY
SA04 5054513025 TACT SWITCH SKHHLV1720-TT DC12V 50MA GRAY
SA05 5054513025 TACT SWITCH SKHHLV1720-TT DC12V 50MA GRAY
SA06 5054513025 TACT SWITCH SKHHLV1720-TT DC12V 50MA GRAY
ViewSonic Corporation
Confidential – Do Not Copy
P90f-1
