54
SEMICONDUCTOR.
DIODE
CKT NO Part no. Description
D901* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D902* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D903# 6611036040 DIODE RECTIFIER BAV21
D904 6613004934 DIODE SWITCHING 1SS133
D913* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D931* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D932* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D933# 6611036040 DIODE RECTIFIER BAV21
D934 6613004934 DIODE SWITCHING 1SS133
D941* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D943* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA ((RA.RB.RC.RD)
D961* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D962* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D963 6611036040 DIODE RECTIFIER BAV21
D964 6613004934 DIODE SWITCHING 1SS133
D966 (RA) 6615009752 DIODE ZENER RD6.8EB2-T7
D966 (RB) 6615007234 DIODE ZENER HZ7B1-TD 6.7-7V
D973* 6613003032 DIODE SWITCHING 1N4148-TD 75V 150mA (RA.RB.RC.RD)
D974 6615007834 DIODE ZENER HZ5C1 4.9-5.1V
D990 6611070541 DIODE RECTIFIER SBD 1N5817
PS: * 1N4148 RA 6613003032 RB 6613003037 RC 6613003048
# BAV21 RA6611036040 RB 6611032741
IC
I901 6644076905 IC, LINEAR VIDEO PER.AMP.M52743BSP SDIP-36
I903 6645008907 IC, DIGITAL OSD MTV038N20 DIP-20
I904 6644009606 IC, LINEAR VIDEO AMP. LM2435 T 9PIN
COIL
L905 5062122946 CORE, BEAD RH03506AT-B
L906 5062133201 BEAD CORE
L907 6119210605 JUMP WIRE
L911 5062133201 BF30TA-2.5 X 3 X 1B
L912 5064456845 COIL, PEAKING TRF-8568M 0.56UH K
L921 5062122902 CORE, BEAD BL03RN2-R62T4
L935 5062122946 CORE, BEAD RH03506AT-B
