ViewSonic 10 PJ557DC/PJ559DC/PJ560DC
Installation
Connecting the Projector
VGA Cable (D-Sub to D-Sub) VGA (D-Sub) to HDTV (RCA) Cable
Audio Cable S-Video Cable
RS-232 Cable Composite Video Cable
USB Cable
1
5
2
6
3
7
4
Desktop type
Laptop type
41
1
12
7
3
652 5
When connecting cable, power cords of both a projector and external equipment
should be disconnected from AC outlet.
The figure above is a sample connection. This does not mean that all of these
devices can or must be connected simultaneously.
The cables that come with the projector may differ from the above illustration.
The included cables are based on actual shipment delivery.
