ViewSonic TD1630-3 User Manual

10
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls
which display on the screen.
Standby Power On/Off
Power light
Blue = ON
Orange = Power Saving
[1]
Displays the Main Menu or exits the control screen and saves
adjustments.
[2]
Displays the control screen for the highlighted control.
Also a shortcut to toggle analog and digital connection.
▲/▼
Scrolls through menu options and adjusts the displayed control.
Brightness/Contrast (▼) / Audio Adjust (▲)
Do the following to adjust the display setting:
1. To display the Main Menu, press button [1].
NOTE: All OSD menus and adjustment screens disappear automatically after
about 15 seconds. This is adjustable through the OSD timeout setting in the
setup menu.
2. To select a control to adjust, press ▲ or ▼ to scroll up or down in the Main
Menu.
3. After the desired control is selected, press button [2].
4. To save the adjustments and exit the menu, press button [1] until OSD
disappear.
The following tips may help you optimize your display:
• Adjust the computer’s graphics card to support a recommended timing mode
(refer to “Specifications” page for recommended setting specific to your LCD
display). To find instructions on “changing the refresh rate”, please refer to the
graphics card’s user guide.
• If necessary, make small adjustments using H. POSITION and V. POSITION
until the screen image is completely visible. (The black border around the edge
of the screen should barely touch the illuminated “active area” of the LCD
display.)

ViewSonic TD1630-3 Specifications

General

Panel type	TN
Pixel pitch	0.252 x 0.252 mm
Screen shape	Flat
Response time	12 ms
Display diagonal	15.6 \
Touch technology	Multi-touch
Touchscreen type	Multi-user
Display brightness	220 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	56 - 75 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 61 kHz
Touchscreen technology	Projected capacitive system
Viewing angle, vertical	60 °
Contrast ratio (typical)	500:1
Display number of colors	262144 colors
Display diagonal (metric)	39.6 cm
Viewing angle, horizontal	90 °
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 720 x 576, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 870, 1280 x 720 (HD 720), 1366 x 768
Number of simultaneous touchpoints	10
Certification	CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, BIS
Product color	Black
Display viewable area (HxV)	344.23 x 193.54 mm
Cables included	AC, Audio (3.5mm), USB, VGA
Audio input	1
HDMI version	1.4
Tilt angle range	15 - 50 °
Panel mounting interface	75 x 75 mm
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	5.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Package depth	86 mm
Package width	453 mm
Package height	389 mm
Package weight	2500 g
NVIDIA G-SYNC	No
Windows operating systems supported	Windows 10, Windows 7, Windows 8
RMS rated power	2 W
Number of speakers	2
Sustainability certificates	CE, ErP, REACH, RoHS
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	37.15 mm
Width (with stand)	379.24 mm
Height (with stand)	247.12 mm
Weight (with stand)	1320 g
