18
Limited Warranty
ViewSonic
®
LCD Display
What the warranty covers:
ViewSonic warrants its products to be free from defects in material and workmanship, under normal
use, during the warranty period. If a product proves to be defective in material or workmanship during
the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product.
Replacement product or parts may include remanufactured or refurbished parts or components.
How long the warranty is effective:
ViewSonic LCD displays are warranted for between 1 and 3 years, depending on your country of
purchase, for all parts including the light source and for all labour from the date of the first consumer
purchase
Who the warranty protects:
This warranty is valid only for the first consumer purchaser.
What the warranty does not cover:
1. Any product on which the serial number has been defaced, modified or removed.
2. Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product
modification, or failure to follow instructions supplied with the product.
b. Any damage of the product due to shipment.
c. Removal or installation of the product.
d. Causes external to the product, such as electrical power fluctuations or failure.
e. Use of supplies or parts not meeting ViewSonic’s specifications.
f. Normal wear and tear.
g. Any other cause which does not relate to a product defect.
3. Any product exhibiting a condition commonly known as "image burn-in" which results when a
static image is displayed on the product for an extended period of time.
4. Removal, installation, one way transportation, insurance, and set-up service charges.
How to get service:
1. For information about receiving service under warranty, contact ViewSonic Customer Support
(Please refer to Customer Support page). You will need to provide your product's serial number.
2. To obtain warranty service, you will be required to provide (a) the original dated sales slip, (b)
your name, (c) your address, (d) a description of the problem, and (e) the serial number of the
product.
3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic
service center or ViewSonic.
4. For additional information or the name of the nearest ViewSonic service center, contact
ViewSonic.
Limitation of implied warranties:
There are no warranties, express or implied, which extend beyond the description contained herein
including the implied warranty of merchantability and fitness for a particular purpose.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ViewSonic TD1630-3 and is the answer not in the manual?

ViewSonic TD1630-3 Specifications

General IconGeneral
Panel typeTN
Pixel pitch0.252 x 0.252 mm
Screen shapeFlat
Response time12 ms
Display diagonal15.6 \
Touch technologyMulti-touch
Touchscreen typeMulti-user
Display brightness220 cd/m²
Display resolution1366 x 768 pixels
Display technologyLCD
Native aspect ratio16:9
Vertical scan range56 - 75 Hz
Maximum refresh rate60 Hz
Horizontal scan range30 - 61 kHz
Touchscreen technologyProjected capacitive system
Viewing angle, vertical60 °
Contrast ratio (typical)500:1
Display number of colors262144 colors
Display diagonal (metric)39.6 cm
Viewing angle, horizontal90 °
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 720 x 480, 720 x 576, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 870, 1280 x 720 (HD 720), 1366 x 768
Number of simultaneous touchpoints10
CertificationCE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, BIS
Product colorBlack
Display viewable area (HxV)344.23 x 193.54 mm
Cables includedAC, Audio (3.5mm), USB, VGA
Audio input1
HDMI version1.4
Tilt angle range15 - 50 °
Panel mounting interface75 x 75 mm
AC input voltage100-240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Power consumption (typical)5.5 W
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)20 - 85 %
Package depth86 mm
Package width453 mm
Package height389 mm
Package weight2500 g
NVIDIA G-SYNCNo
Windows operating systems supportedWindows 10, Windows 7, Windows 8
RMS rated power2 W
Number of speakers2
Sustainability certificatesCE, ErP, REACH, RoHS
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)37.15 mm
Width (with stand)379.24 mm
Height (with stand)247.12 mm
Weight (with stand)1320 g
