ViewSonic TD1630-3 User Manual

11
Main Menu Controls
Adjust the menu items by using the up ▲ and down ▼ buttons.
NOTE: Check the Main Menu items on your LCD OSD and refer to Main Menu
Explanation below.
Main Menu Explanation
NOTE: The Main Menu items listed in this section indicates whole Main Menu items
of all models. The actual Main Menu details corresponding to your product please
refer to your LCD OSD Main Menu items.
A
Audio Adjust
adjusts the volume, mutes the sound, or toggles between inputs if you
have more than one source.
Auto Image Adjust
automatically sizes, centers, and fine tunes the video signal to eliminate
waviness and distortion. Press the [2] button to obtain a sharper image.
NOTE: Auto Image Adjust works with most common video cards. If this
function does not work on your LCD display, then lower the video refresh
rate to 60 Hz and set the resolution to its pre-set value.
B
Brightness
adjusts background black level of the screen image.
C
Color Adjust
provides several color adjustment modes, including preset color
temperatures and a User Color mode which allows independent
adjustment of red (R), green (G), and blue (B). The factory setting for this
product is native.
Contrast
adjusts the di󰀨erence between the image background (black level) and
the foreground (white level).
I
Information
displays the timing mode (video signal input) coming from the graphics
card in the computer, the LCD model number, the serial number, and
the ViewSonic
®
website URL. See your graphics card’s user guide
for instructions on changing the resolution and refresh rate (vertical
frequency).
NOTE: VESA 1024 x 768 @ 60Hz (example) means that the resolution is
1024 x 768 and the refresh rate is 60 Hertz.

ViewSonic TD1630-3 Specifications

General

Panel type	TN
Pixel pitch	0.252 x 0.252 mm
Screen shape	Flat
Response time	12 ms
Display diagonal	15.6 \
Touch technology	Multi-touch
Touchscreen type	Multi-user
Display brightness	220 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	56 - 75 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 61 kHz
Touchscreen technology	Projected capacitive system
Viewing angle, vertical	60 °
Contrast ratio (typical)	500:1
Display number of colors	262144 colors
Display diagonal (metric)	39.6 cm
Viewing angle, horizontal	90 °
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 720 x 576, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 870, 1280 x 720 (HD 720), 1366 x 768
Number of simultaneous touchpoints	10
Certification	CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, BIS
Product color	Black
Display viewable area (HxV)	344.23 x 193.54 mm
Cables included	AC, Audio (3.5mm), USB, VGA
Audio input	1
HDMI version	1.4
Tilt angle range	15 - 50 °
Panel mounting interface	75 x 75 mm
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	5.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Package depth	86 mm
Package width	453 mm
Package height	389 mm
Package weight	2500 g
NVIDIA G-SYNC	No
Windows operating systems supported	Windows 10, Windows 7, Windows 8
RMS rated power	2 W
Number of speakers	2
Sustainability certificates	CE, ErP, REACH, RoHS
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	37.15 mm
Width (with stand)	379.24 mm
Height (with stand)	247.12 mm
Weight (with stand)	1320 g
