Product Overview
Front View
321 4 5 6 7
Number Item Descripon
1 Power Buon
• Power On (Green light)
• Power O (No light)
• When the VBS200-A system is On, pressing the Power
Buon will put the VBS200-A into Sleep Mode.
2 Reset
Hardware reset of the device.
3 USB 2.0 C Port
USB 2.0, 500mA¹
4 USB 3.0 A Port
USB 3.0, 900mA¹
5 USB 2.0 A Port
USB 2.0, 500mA¹
6 MicroSD
Read/Write MicroSD card
7 AUDIO OUT
Audio signal output (3.5 mm DAC)
1 Supports USB and UVC devices/Touch Back/Hot swapping and plugging
