DisplayPort/USB Type C MST Daisy Chain Connecon
With DisplayPort/USB Type C Mul-Stream Transport (MST) support, you can daisy
chain connect up to two (2) monitors.
NOTE: Your graphics card should be DP 1.2 compliant and support MST mode.
1. Connect one end of a DisplayPort/USB Type C cable to the DisplayPort Out/USB
Type C Out port of your computer. Then connect the other end of the cable to the
DisplayPort In/USB Type C In port of the monitor.
2. Use another DisplayPort cable to connect to the DisplayPort Out port of the rst
monitor. Then connect the other end of the cable to the DisplayPort In port of
the second monitor.
Type-C
Out
In
Out
In
Out
In
1
Type-C Type-C
2
Or
NOTE:
• The max resoluon is 2560 x 1440.
• DisplayPort 1.2 MST must be turned on in the Setup Menu in the OSD
Menu to do daisy chaining.
• If the input source changes to HDMI, DisplayPort 1.2 MST will turn o
automacally.
DisplayPort
In
DisplayPort
Out
USB C
