51
Advanced Features and Sengs
This secon describes advanced features of the monitor.
KVM
The KVM funcon allows the user to control two computers connected to the same
monitor from a single keyboard and mouse.
NOTE: Only applicable in PBP (Picture-by-Picture) mode.
To connect the two computers to the monitor:
1. Connect one end of the USB Type C cable to the USB Type C port of the monitor.
Then connect the other end of the cable to the USB Type C port of the notebook.
2. Connect one end of a DisplayPort cable to the DisplayPort of the monitor. Then
connect the other end of the cable to the DisplayPort or mini DP of the computer.
3. Connect the USB Type B male cable (square with 2 cut corners) to the USB Type B
port of the monitor. Then connect the other end of the cable to the USB port of
the computer.
Type-C
Type-C
