HDMI Connection
DisplayPort Connection
USB Connection
Connect one end of an HDMI cable to the HDMI port of your monitor. Then connect the other end of
the cable to the HDMI port of your computer.
NOTE: The monitor is equipped with two HDMI 2.0 ports.
Connect one end of a DisplayPort cable to the DisplayPort port. Then connect the other end of the
cable to the DisplayPort or mini DP port of your computer.
NOTE: To connect the monitor to the Thunderbolt port (v. 1&2) on your Mac, connect the mini DP end
of the “mini DP to DisplayPort cable” to the Thunderbolt output of your Mac. Then connect the other
end of the cable to the DisplayPort port of the monitor.
HDMI
DisplayPort
USB
