Installation
ViewSonic VPC190 9
Attaching the Stand
1. Lay the All-in-One PC on a flat and stable surface.
2. Use a soft cloth to protect the display screen.
3. Attach the stand. Tighten the stand until it is firmly locked in place. Tighten the
3 screws on the bottom of the stand.
Tilting the Screen
After installing the stand, the screen can be tiled up to 20° to suit user’s
preference.
Removing the Stand
Should there be a need to detach the stand (i.e., for wall mounting), follow the steps
below:
1. Lay the All-in-One PC on flat and stable surface. Use a soft cloth to protect the
display screen.
2. Remove the 3 screws located on the bottom of the stand(A)
3. Pull the stand off (B)
SD/MMC/MS
SD/MMC/MS
