DVI Connection
☼
• If the equipment has a DVI jack and not an HDMI jack, connect the DVI jack to the
HDMI1 jack [3] or HDMI2 jack [6], and connect the audio jack to
the AUDIO In jacks of PC Audio input [12].
• HDMI1 jack [3] jack mainly supports PC signal, with audio connected from PC Audio
input [12]. HDMI2 jack [6] jack is recommended for video signal.
YPbPr or Component Connection
HD cable box/
HD satellite box
CATV/Satellite
antenna cable
Rear of TV
Component video cable
Audio cable
CATV/Satellite
antenna cable
HD cable box/
HD satellite box
Audio cable
DVI-to-HDMI cable
Rear of TV
or
