- 27 –
ViewSonic Corporation
Confidential - Do Not Cop VX2262wm/wmp
2. Geometry
1).Set cross-hatch pattern and preset timing as timing table listed.
2).Change to each mode in turn and wait for the monitor finish auto-alignment and save
press before change to next mode.
3).Until all of modes are adjusted, exit OSD menu and press POWER OFF to exit factory
mode.
5.4 Factory Defaults
Item Defaults Item Defaults
Contrast 70% OSD Time Out 15 Sec
Brightness 100% OSD Background On
Color Temperature 6500K Volume 70%
Sharpness 50% Treble N/A
OSD H. Position 50% Bass N/A
OSD V. Position 50% Input Priority Auto Search
720x400 / 640x400 720x400 Dynamic Contrast Off
Resolution Notice On Aspect Ratio Full screen
Response Time Advanced
5.5 Function Test
1 Product: 22” LCD Monitor
2 Test Equipment: Color Video Signal & Pattern (or PC with SXGA resolution)
3 Test Condition: Before function test and alignment, each LCD Monitor should be
warmed up for at least 30 minutes with the following conditions:
(a)In room temperature,
(b) With full-white screen, RGB, and Black
(c) With cycled display modes,
640*480 (H=43.27kHz, V=75Hz)
800*600 (H=53.7kHz, V=75Hz)
1024*768 (H=68.67kHz, V=60Hz)
1280*1024 (H=79.97kHz, V=60Hz)
1440*900 (H=55.9kHz, V=60Hz)
1680 x 1050 (H=5.3kHz, V=60Hz)
4 Test Display Modes & Pattern
Compatible Modes
Item Timing Analog
1 640 x 480 @ 60Hz, 31.5kHz
Yes
2 640 x 480 @ 75Hz, 31.5kHz Yes
3 720 x 400 @ 70Hz, 31.5kHz
Yes
4 800 x 600 @ 56Hz, 35.1kHz
Yes
5 800 x 600 @ 60Hz, 37.9kHz
Yes
6 800 x 600 @ 72Hz, 48.1kHz
Yes
7 800 x 600 @ 75Hz, 46.9kHz
Yes
8 1024 x 768 @ 60Hz, 48.4kHz
Yes
9 1024 x 768 @ 70Hz, 56.5kHz
Yes
10 1024 x 768 @ 72Hz, 58.1kHz
Yes
