ViewSonic VX910 Service Manual

Information
displays the timing mode (video signal input)
coming from the graphics card in your computer. See your
graphic card’s user guide for instructions on changing the
resolution and refresh rate (vertical frequency).
NOTE:
VESA 1280 x 1024 @ 60 Hz (recommended) means
that the resolution is 1280 x 1024 and the refresh rate is 60
Hertz.
Manual Image Adjust
displays the Manual Image Adjust menu.
The
Manual Image Adjust
controls are explained below:
Horizontal Size
adjusts the width of the screen image.
Horizontal Position
moves the screen image left or right.
Vertical Position
moves the screen image up or down.
Fine Tune
sharpens focus by aligning the illuminated text and/
or graphic characters.
Sharpness
adjusts the clarity and focus of the screen image.
Control Explanation
H . / V . Position
Manual Image Adjust
1: Exit 2 : Select
H . Size
Fine Tune
Sharpness
H. Frequency: 31.47 KHz
Information
V. Frequency: 31.47 Hz
Pixel Clock: 24.80 MHz
Resolution: 640 x 480
Model No. :
Serial No. :
www.viewsonic.com
1: Exit
7
ViewSonic Corporation Confidential
-
Do Not Copy VX910

ViewSonic VX910 Specifications

General

Pixel pitch	0.294 mm
Response time	16 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	24 - 82 kHz
Viewable size, vertical	301 mm
Viewable size, horizontal	376 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	250 cd/m²
Certification	TCO’99, TÜV/GS, TÜV/ERGO, ISO13406-2 (class 2), CE, UL, cUL, FCC-B, CB, ENERGY, NOM, NEMKO, NEMKO ERGO, GOST-R, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, Argentina-S, Green Mark
Market positioning	-
Power management	TCO’99, ENERGY Standards
Tilt angle range	5 - 20 °
Compatibility	PC/Mac
Operating relative humidity (H-H)	10 - 90 %
Maximum operating temperature range (T-T)	0 - 40 °C

Weight and Dimensions

Depth (without stand)	468 mm
Width (without stand)	431 mm
Height (without stand)	201 mm
Weight (without stand)	6700 g
