ViewSonic VX910 Service Manual

Mechanical :
Dimension ( W x H x D ) mm
Set : a. with stand : 430.8 x 468.4 x 201 mm
b. Without stand : 430.8 x 370.2 x 66.2 mm
Slim bezel : 19.0 / 19.0 / 22.0 / 22.0
Base (L X W) : 286 x 201 mm
Packing : ( W x H x D ) mm : 496 x 532 x 247 mm
Weight : Net / Gross ( Kg ) : 6.7 / 8.5
Wall Mount (VESA) : 100 x 100 mm
LCD Panel type : LG / LM190E03 Rev.03
Max. resolution (HxV) : 1280 x 1024
Nominal picture size (HxV) : 376.3 mm x 301.1 mm
Display colors : 16.2 M ( 6 bit + dithering )
Dot pitch : 0.264 mm
Response time : 4+12 / 16ms (Tr + Tf / typical)
Brightness (100% white) : Typical : 250 cd/m² , Min. 200cd/m²
Contrast : Typical : 500:1, Min. 300:1
Viewing angle : 70 / 70 /70 / 70 (L/R/T/B CR>=10)
Synchronization : Fh = 31~82 KHz / Fv=50~75Hz
Presets : 26 timing modes
OSD Languag : 8 kinds languages
Color Temperature : sRGB , 6500°K (default) / 9300°K
/5400°K / User R,G,B
Plug & Play : DDC1/2B interface
Scaler chip : Mstar MST8131a
AC Power range : 90 V ~ 264 V, 50 Hz / 60 Hz
Power consumption : < 40W green / < 1W amber
(On / Off mode)
2. Specification
2
ViewSonic Corporation Confidential
-
Do Not Copy VX910

ViewSonic VX910 Specifications

General

Pixel pitch	0.294 mm
Response time	16 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	24 - 82 kHz
Viewable size, vertical	301 mm
Viewable size, horizontal	376 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	250 cd/m²
Certification	TCO’99, TÜV/GS, TÜV/ERGO, ISO13406-2 (class 2), CE, UL, cUL, FCC-B, CB, ENERGY, NOM, NEMKO, NEMKO ERGO, GOST-R, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, Argentina-S, Green Mark
Market positioning	-
Power management	TCO’99, ENERGY Standards
Tilt angle range	5 - 20 °
Compatibility	PC/Mac
Operating relative humidity (H-H)	10 - 90 %
Maximum operating temperature range (T-T)	0 - 40 °C

Weight and Dimensions

Depth (without stand)	468 mm
Width (without stand)	431 mm
Height (without stand)	201 mm
Weight (without stand)	6700 g
