Page 10
ITM-0060-0069-ED3
Specifi cations
Supply voltage 230 V~ 230/400 V~ (selectable)
Admissible voltage variation ±20% (>30%: auto power-off) ±20% (>30%: auto power-off)
Maximum intensity 18 Amp AC3 12 Amp AC3 (16 or 23 a/model)
Overload adjustment (Amp. max) 1-18 Amp 1-12 Amp (16 or 23 a/model)
Underload adjustment (Amp. min) 1-18 Amp 1-12 Amp (16 or 23 a/model)
Overload trip time 7 s 7 s
Underload trip time 4 s 4 s
Re-start time 15 minutes (fi xed) 15 minutes (fi xed)
Capacitor maximum capacity 80 μF (50 μF inside the equipment) -
Probes operating voltage 24 V~ 24 V~
Probes sensitivity 9 KΩ 9 KΩ
Remote control connection Contact or voltage 6 to 400 V~/V= Contact or voltage 6 to 400 V~/V=
Alarm output contact AC1 : 2 A / 250 V~
AC11 : 1 A / 230 V~
AC1 : 2 A / 250 V~
AC11 : 1 A / 230 V~
Control terminal blocks 4 mm² 4 mm²
Mounting Wall mounting with fi xing points Wall mounting with fi xing points
Size (mm) 200 x 150 x 80 255 x 195 x 95
Weight 850 g 1,5 Kg
Working temperature -10 + 55 ºC -10 + 55 ºC
Protection IP56 IP56
Vigilec mono (V1M) Vigilec mini (V1N)
EC DECLARATION OF COMPLIANCE WITH THE “LOW VOLTAGE” & “ELECTROMAGNETIC COMPATIBILITY” DIRECTIVES.
TOSCANO LINEA ELECTRONICA, S.L. declares that the equipment described in this manual complies with the provisions of the modifi ed “LOW VOL-
TAGE” directive (Directive DC 2004/108/CE) and with the modifi ed “ELECTROMAGNETIC COMPATIBILITY” directive (Directive DC 2006/95/CE) and
with national legislation based upon them. It also complies with the provisions of the following European standards and draft standards:
NF EN 60.439-1 / EN 50.081-1 / EN 50.082-2 .
