16
Wok Conversion
(for models equipped with wok)
Remove center trivet and/or grates, center ring and grate support.
Lift and remove burner from unit.
Loosen air shutter screw and adjust opening on burner to 5/8” and tighten air shutter screw.
Remove orifice by turning counterclockwise and replace with orifice from bag labeled Wok
Orifice.
IMPORTANT: The orifice tip must be located 3/16” inside the burner for proper gas mixture
and combustion. The depth of the orifice can be adjusted by turning the orifice
counterclockwise (more depth) or clockwise (less depth).
Reverse procedures as needed to reassemble.
Overhead
View
Air
Shutter
Orifice
