Viking VCBB360R - Electronic Control Board Description; High Voltage Control Board Wiring Schematic

12
Electronic Function Description
WARNING: To avoid electrical shock which can cause severe personal injury or death, disconnect
power to refrigerator using power switch before servicing. Wires removed during disassembly must be
replaced on proper terminals to insure earth ground and polarization. After servicing, reconnect power
using power switch.
