Component Specifications
Component Description Test Procedures
Bulb Volts 120VAC
Watts 40 watts
Capacitor, compressor run Volts 220VAC
Capacitance 15 µfc + 10%
- 5%
Compressor Type Fan cooled, R134a refrigerant
BTUH 970 BTUH
Volts 120VAC 60Hz
Watt 176 watts
Current: Lock rotor 21.3 A
Full load !.6 A
Resistance: Run windings 2.60Ω
Start windings 4.35Ω
Drier Drier must be changed every time the system is opened
for testing or compressor replacement.
Desiccant (20) 8x12.4AXH – 7 M. S.-Grams
Heater, evaporator Volt 120VAC
Wattage 450 ±5% W
Resistance 30 ± 5% Ω
8B
