TROUBLESHOOTING GUIDE ---Dual Fuel / Self-clean / VDSC - VESO 105 - VED0 205---
PROBLEM PROBABLE CAUSE CORRECTION
A. No Bake, No Broil A-1 House Breaker or fuse open A-1 Reset Breaker or replace fuse
No Cycle Light, No
Power to Relay #1.
B. No Bake, No Broil B-1 Timed Bake/Broil function switch B-1 Set Timed Bake/Broil function
No Cycle Light set to Timed function (wall ovens) switch to manual.
Power to Relay #1
(Red – Red/Black) B-2 Power Relay #1 Heater circuit open B-2
Replace Power Relay #1 (Relay
terminals #1 & #3) (Power Relay test procedure pg 24) #1 Part# PM010026)
No power to Relay
#1 Heater. B-3 Open contacts Relay #2 (single / upper B-3
Replace Relay #2 (single / upper
oven) (wh/red wire to neutral pins #1 oven or Relay #5 (lower oven)
and #7). Open contacts relay #5 (lower (
Relay #2 & #5 part # PM010029)
oven). (blue wire to neutral pins #1
and #7)
B-4 Open contact Relay #3 (single / upper B-4
Replace Relay #3 (upper oven) or Relay
oven) (red/blu contact #3 to wh/vio #9 (lower oven) (Relay PN 010029)
Contact #9) or open contact Relay #6
(lower oven) (Brown contact #3 to wh/
vio contact #9)
B-5 Open Thermostat cycling contacts B-5 Replace Thermostat
#1 and # 2
B-6 Open High Limit Switch (contacts B-6 Replace High Limit Switch
normally closed)
C. No Bake Functions C-1 Open Bake Element (see pg #21 for C-1 Replace Bake Element
Broil functions
normally and the C-2 Open selector switch contacts 1 to L2 C-2 Replace Selector Switch
Cycle Light is on (See pg # 22 for selector Switch
contact checks)
C-3 Burned Wiring of Terminal connections C-3 Replace or Repair burned wiring and / or
Terminals (spade) connections.
D.
Poor Baking Results D-1 Low Voltage Supply (240 VAC D-1 Inform Customer of requirements.
Broil functions required).
Normally, Cycle
Light is on. D-2 Restricted Air Flow through the oven D-2 Clear restriction from oven vent.
cavity.
D-3 No Top Heat from Broil Element. D-3 Rep lace Selector Switch
Open Selector Switch contacts 3 to E
(see Pg #22 for selector switch checks)
D-4 Check Use and Care for suggested
baking tips.)
