Service
Manual
Built-In
Side by Side
Non-Dispenser
Refrigerator /
Freezer
Preferred Service
FDSB5421
FDSB5481
VCSB5421
VCSB5481
SMR-0020
MAY 2012
®
This manual is to be used by qualied appliance technicians only. Viking
does not assume any responsibility for property damage or personal
injury for improper service procedures done by an unqualied person.
This Base Manual covers general and
specic information including, but not
limited to the following models:
