10
VOADDR5421 - 42” DOOR / DRAWERS
Product Dimensions
TOP
VIEW
18-3/4”
(47.6 cm)
19”
(48.3 cm)
21-5/8”
(54.9 cm)
39-5/8”
(100.6 cm)
22-1/8”
(56.2 cm)
Clearance
Radius
FRONT
VIEW
42”
(106.7 cm)
19-1/2”
(49.5 cm)
21-1/8”
(53.7 cm)
18-3/8”
(46.7 cm)
9-1/4”
(23.5 cm)
18-3/8”
(46.7 cm)
Cutout Dimensions
TOP VIEW
SIDE
VIEW
FRONT
VIEW
20”
(50.8 cm)
Deep
1-1/2”
(3.8 cm) MIN
3-1/2” (7.6 cm)
MIN
19”
(48.3 cm)
High
19”
(48.3 cm)
20”
(50.8 cm)
39-3/4” (101.0 cm)
