Viking VOADS5181 - Page 2

2
VOADS5181 - 18” DOOR
15-5/8”
(39.7 cm)
2-3/8” (6.0 cm)
16-5/8”
(42.2 cm)
18”
(45.7 cm)
21-1/8”
(53.7 cm)
18-1/2”
(47.0 cm)
15-3/8”
(39.1 cm)
Clearance
Radius
18-3/4”
(47.6 cm)
2-3/8”
(6.0 cm)
1-1/4”
(3.2 cm)
Product Dimensions
Cutout Dimensions
TOP
VIEW
SIDE
VIEW
FRONT
VIEW
TOP VIEW
SIDE
VIEW
FRONT
VIEW
3” (7.6 cm)
Deep
15-3/4”
(40.0 cm)
19”
(48.3 cm)
High
1-1/2”
(3.8 cm) MIN
19”
(48.3 cm)
3” (7.6 cm)
3-1/2” (7.6 cm)
MIN
