5
VOADD5301 - 30” DOOR
28”
(71.1 cm)
15-1/8”
(38.4 cm)
Clearance
Radius
Product Dimensions
SIDE
VIEW
FRONT
VIEW
30”
(76.2 cm)
13-7/8”
(35.2 cm)
2-1/4”
(5.7 cm)
1-1/4”
(3.2 cm)
18-3/8”
(46.7 cm)
21-1/8”
(53.7 cm)
18-3/4”
(47.6 cm)
TOP VIEW
SIDE
VIEW
FRONT
VIEW
3” (7.6 cm)
Deep
28-1/4”
(71.8 cm)
19”
(48.3 cm)
High
1-1/2”
(3.8 cm) MIN
19”
(48.3 cm)
3” (7.6 cm)
3-1/2” (7.6 cm)
MIN
