Safety and Technical Manual
Rev: 2
Form No. F_020521
VSF303 Flame Detector
This document is strictly private and confidential, reproduction without Viking Corporation approval is prohibited. © 2021 The Viking Group Inc.
Internal Inter-connections
The following diagram shows the internal inter-connections of the alarm and fault relay contacts and
jumpers. Each field connection is listed on this diagram for clarity.
Figure 7: VSF303 Internal Inter-connections
