Certification and Approvals
Parameter
Authority/
Standard
Approval
Certificate*
Hazardous Area
Certification
ATEX
Ex II 2 G Ex db II C T4Gb IP66
FM21ATEX0029X
Hazardous Area
Certification
NEC 505
Class1 Zone 1 A Ex db IIC T4
PR460215
Hazardous Area
Certification
NEC 500
Class 1 Div 1, Groups B, C, D
T4
PR460215
Hazardous Area
Certification
IECEx
Ex II 2 G Ex db II C T4Gb IP66
IECEx FME 21.0004X
American Fire Service
Listing
FM
Class 3260, 3615, 3600
PR460215
European Fire Services
Listing
FM
EN 54 Part 10 2002
2809-CPR-E0023
CE Marked (Emissions)
Element
EN61000-6-3:2007A1:2011
TRA-037863-35-00A
CE Marked (Immunity)
FM
EN50130-4 2011 A1:2014
9313-1
IEC 61508
exida
Certified SIL 2 Capable
VIK 2104078 C002
Operating Specification
Parameter
Units
Min
Max
Comment
Detector Range (depth of field)
ft / m
6.5 / 2.0
200 / 60
Horizontal Field of View
Degrees
90
90
Vertical Field of View
Degrees
90
90
Detector Response Time
Seconds
4.0
30
Power on reset delay
Seconds
5
5
Parameter
Value
Detector sensitivity
Low, Standard (Factory default) and High.
Alarm Setting
Non-latching with automatic reset after 15 seconds (default)
OR latched until the power is removed from detector.
Advanced Optical Verification
Yes – no mirror continuous automatic optical verification
Heated Optics
Yes – microprocessor controlled
LED Status
Tri-state LED – Green HEALTHY; Yellow FAULT; Red
ALARM
Output Options
0(4)-20mA, HART® 7, Relay contacts - alarm and fault
Relay Rating
2 Relay Contacts – Alarm and Fault. DPDT, 2A @ 30Vdc
Communication/ Configuration
RS485 and HART® 7
