PROBLEM CHECK POSSIBLE CAUSE REMEDY
b. Light activation 1. Failed light activation 1. Replace light activation
switch. switch. switch.
c. Wiring 1. Improperly wired bypass 1. Correct improper wiring
connection to switch or over-ride connections
and from light switch.
activation switch
and over-ride
switch.
d. Position of door 1. If over-ride switch is in 1. Place over-ride switch in
light activation the “on” position instead the “door” position. Verify
over-ride switch of the “door” position, light goes out when door
is in the “on” the light will remain on is closed by depressing
position. with the door closed. light activation switch
This is intended for and confirming light goes
glass door viewing out.
with door closed.
e. Over-ride switch 1. Failed over-ride switch. 1. Replace over-ride switch.
operation.
THERMOSTAT SPECIFICATIONS
VUAR—VRBD—VUBD
Thermostat (°F) (°F)
Knob Setting Cut-In Cut-Out
Warmest
Setting No. 1 38° ± 2.7° 7.5° ± 2.7°
Mid
Setting No. 3 ½ 38° ± 1.5° 1° ± 2°
Coldest
Setting No. 7 38° ± 2.7° .6° ± 2.7°
• Light bulb is intermediate 15 watt bulb. DO NOT use a higher wattage bulb.
• Optional item.
F90571
13
