13
Preparation and Filling
Fill the spa to its correct operating level. Be sure to open all
valves in the JetPaks and all other jets in the spa before filling to
allow as much air as possible to escape from the system during
the filling process. For details see “Filling your spa” section. After
turning the power on at the main power panel, the control panel
display will go through an initializing sequence. is sequence
displays information regarding the configuration of the hot tub
control. After a few seconds, your control will display a standard
status screen with time, jet and light status, temperature status,
operation mode, etc.
Power
Press any button to turn the keypad on. After 30 minutes without
activity it will shut off.
Priming the Pumps
After initial start-up, verify that the home status screen appears
on the panel. Pumps must be primed directly after filling to
ensure correct operation of your spa. To prime the pumps press
the “Jets 1” button once to prime in low-speed. After the
pump turns on wait a few seconds and then press “Jets 1”
again to initiate high-speed operation of Pump 1. e pump has
primed when the jets are running with water flowing from the
jets. Press the “Jets 1” button again to turn off Pump 1.
If your spa is equipped with a second jet pump repeat the priming
process for Pump 2 by pressing the “Jets 2” button once to
turn on low speed and then a second time to turn Pump 2 on
high. Each pump should run for 4-5 minutes at their highest
speed to complete priming. Prime each pump separately and turn
off before priming the next pump. Once primed, allow pumps to
run at high speed for a few minutes before shutting off.
If you have the A9L model your spa will be equipped with 3
jet pumps. To prime your A9L jet pumps press the “Jets 1”
button once to prime in filtration speed. After the pump turns
on wait a few seconds and then press “Jets 1” again to prime
the first jet pump. Wait a few seconds, press “Jets 1” again
to prime the second jet pump. Wait a few seconds, then finish
priming by pressing “Jets 1” again to prime the third jet
pump. All pumps will have primed when all jets are running at
high speed with water flowing from the jets. Once primed, allow
pumps to run at high speed for a few minutes before shutting off.
IMPORTANT: Pumps should not be allowed to run without
priming (no water flowing out of the jets) for more than 2
minutes. Under NO circumstances should a pump be allowed to
run without priming beyond the end of the 4-5 minute suggested
priming time. Doing so may cause damage to the pump(s) and
cause the system to energize the heater without water flow,
potentially resulting in an overheat condition.
NOTE: Sometimes momentarily turning the pump off and
on will help it to prime. Do not do this more than 5 times. If the
pump(s) will not prime, shut off the power to the spa and call for
service.
Once you have completed priming, the home status screen will
display the set temperature. e system requires approximately
1-2 minutes of water flowing through the heater to determine
and display the correct water temperature.
Design/Premium Line Spas
Premium Line Control
Design Line Control
