Maintenance and cleaning
9. Connect the battery unit to the controller by clicking the lugs in place.
10. Reconnect the cable between battery unit and the controller.
11. Insert the battery unit and controller into the urinal through the service channel.
12. Fix the battery unit and the controller to the siphon on the urinal by engaging the clamp.
17.2 Sieve seal
Important
The urinal and parts of the flushing system must be removed in
order to clean the basket filter. To do this, carry out the steps in
the reverse sequence to that shown in the separate installation
instructions.
Remove and clean the sieve seal at regular intervals, depending on the level of contamination in
the water.
The sieve seal is installed in the solenoid valve housing in the water circuit inlet.
When fitting the sieve seal you must ensure that it is fitted in the correct position on the
solenoid valve (see also separate installation instructions).
S. 80
