3.3 Congurations via push button
The conguration envisages that the entrance panel is open and the push buttons removed from the base.
Conguration is done using push buttons 1-2-3-4-5-6-7-8.
21
43
65
87
Blue LED
Red LED
Green LED
3.3.1 Access to push button conguration status
• STARTING THE CONFIGURATION (push button 7 + PIN if enabled)
or to enter the conguration status:
- press and hold down push button 7 for at least 6 s, until the outdoor station emits a conrmation beep and the green
LED is on steady.
- enter the access PIN where enabled (by default 1, 2, 3, 4); the green LED starts to ash.
•
If the PIN is enabled, the device emits a beep, the backlighting LEDs come on and the “enter PIN” signal is enabled;
o the user enters the 4-digit PIN:
- if correct, the outdoor station emits an “input in conguration” beep and the green LED starts to ash. The
status is conguration active.
- if incorrect, an “operation not permitted” beep is given and the red LED ashes. The status is standby.
•
If the PIN is disabled, the device emits a beep and the green LED ashes (see chapter "Signalling during conguration").
The status is conguration active.
• EXIT (Push button 7 / timeout 30 s )
o to exit conguration mode: press and hold down push button 7 (for at least 3 s) until acoustic/visual feedback of exiting
the conguration status is given (the green LED stops ashing and a "beep” is emitted).
