Vimar ELVOX Roxie 40170 User Manual

EN
6
Roxie: 40170
2.2 Internal view (entrance panel open)
b
d
f
e
c
g
h
Push button 2 - FACTORY
Push button 1 - AUDIO
Push button 4 - REBOOT
Push button 3
Push button 6 - AUTO ID
Push button 5
Push button 8 - PAIR.
Push button 7 - IN/OUT
a
a - Cable input
b - Indicator LED
c-d - Connection terminal blocks
e - NO/NC contact conguration jumper
f - Blue LED
g - Conguration dip switch
h - Type C USB connector
