Vimar ELVOX Roxie 40170 User Manual

EN
10
Roxie: 40170
3.2 Congurations via dip-switch
6 dip-switches are available with the conguration functions described in the following table:
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ON
21 3 4 5 6
ID1 ID2
1 push button
(default)
2 push buttons 1 push button 4 push buttons
"CA" "PA"
Internal video External video
Single video Two videos
ON
21 3 4 5 6
ON
21 3 4 5 6
• Due Fili Plus ID
settings
• Selection of the
number of call buttons
• Selection of CA or PA
operation
• Main Video Source
• Number of videos to
display
The SaveProg, app and dip-switch conguration sources have the same priority, the last settings prevail and work exclusively. In
addition, changes of one source are not updated in real time on another.
Settings done from dip-switch are read continuously from the outdoor station (this does not depend on the conguration status).
If the settings from dip switch become obsolete (new programming by SaveProg or app), while the outdoor station is open and
in standby a warning signal ”dip-switches unreliable” will be given (see chapter "LED signalling"), which indicates any dip-switch
conguration as unaligned.
The factory default conguration reset is managed as a forced programming: after a reset the dip-switches are not read (and are
therefore invalidated).
