18
Tab 7S Up 40517
- Collegamento del pulsante fuoriporta (contatto NO/NC; default: NO)
- Connecting the landing push button (NO/NC contact; default: NO)
- Connexion du poussoir appel palier (contact NO/NF ; par défaut : NO)
- Anschluss der Etagenruftaste (NO/NC-Kontakt; Standard: NO)
- Conexión del pulsador fuera de la puerta (contacto NO/NC; predeterminado: NO)
- Ligação do botão de patamar (contacto NO/NC; por defeito: NO)
- Σύνδεση μπουτόν εξώπορτας (επαφή NO/NC, προεπιλογή: NO)
(NO : NO/NC  )       -
E-
2
E+
1
FP
IN
M
CH
*
E-
2
E+
1
FP
IN
M
CH
E-
2
E+
1
FP
IN
M
CH
*
Pulsante di chiamata Fuoriporta
Landing call button
Poussoir d'appel palier
Etagenruftaste
Pulsador de llamada desde fuera de la puerta
Botão de chamada de Patamar
Κουμπί κλήσης εξώπορτας
   
Schemi di collegamento
Wiring diagrams
Schémas de connexion
Anschlusspläne
Esquemas de conexión
Esquemas de ligação
Διαγράμματα σύνδεσης
 
- Posto interno in congurazione entra/esci
- Indoor station in in/out conguration
- Poste intérieur en conguration entrée/sortie
- Innenstelle in Konguration ein/aus
- Aparato interno en conguración entrar/salir
- Posto interno na conguração entrar/sair
- Εσωτερικός σταθμός σε διαμόρφωση εισόδου/εξόδου
/        -
- Posto interno in congurazione terminale
- Indoor station in terminal conguration
- Poste intérieur en conguration terminal
- Innenstelle in Konguration als Endgerät
- Aparato interno en conguración terminal
- Posto interno na conguração terminal
- Εσωτερικός σταθμός σε διαμόρφωση τερματισμού
        -
*
MONTANTE - RISER - COLONNE
MONTANTE - STEIGLEITUNG-
MONTANTE- COLUNA MONTANTE-
ΚΕΝΤΡΙΚΗ ΓΡΑΜΜΗ-   
